point3-learning-tool

Point3 Learning Tool ✨

An accessible English‑learning desktop application designed for visually impaired learners. The app bundles an Electron shell, a React front end, and a Flask backend to deliver guided listening, self‑recording, and pronunciation comparison in a single package.

Features 🎯

• 🖥️ Integrated desktop experience – Electron launches the React interface together with the Flask API; no browser window is required.
• 🧭 Guided learning workflow – Browse curated materials, listen to reference audio, read large‑print transcripts, and control playback with keyboard‑friendly buttons.
• 🎙️ Pronunciation practice – Record user attempts directly in the app; uploads are stored server‑side for evaluation.
• 📊 Waveform comparison & similarity – Visualise reference vs. learner recordings and review an automatically calculated similarity score.
• 🛠️ Admin console – Replace reference audio, review transcripts, and manage content without touching the filesystem.

Tech Stack 🧰

• Front end: React 18, Material UI, React Router, echarts-for-react.
• Desktop shell: Electron 18 with wait-on / concurrently for orchestration.
• Backend: Flask 2.3 + Flask-CORS, Librosa/Numpy for signal analysis.
• Tooling: Python 3.10+, Node.js 18+, npm.

Repository Layout 📂

.
├── app
│   ├── backend/          # Flask API, data stores, sample generation script
│   ├── client/           # React source code and assets
│   ├── main.js           # Electron main process (lanches Flask + React)
│   └── package.json      # Electron + orchestration scripts
├── scripts/              # Cross-platform start scripts
├── README.md             # English README
└── README-zh.md          # 中文说明

Key data directories (created on first run or via create_sample_data.py):

• app/backend/databaseOrigin/ – JSON metadata & transcript .txt files.
• app/backend/audioOrigin/ – Reference audio clips (WAV).
• app/backend/audioSelf/ – User recordings (auto-created).

Getting Started 🚀

Prerequisites 📋

• Python 3.10 or later (python, pip in PATH).
• Node.js 18 or later (node, npm in PATH).
• Recommended: Git Bash or PowerShell on Windows for the provided scripts.

Install dependencies 📦

# Python dependencies
cd app/backend
pip install -r requirements.txt

# JavaScript dependencies (client + Electron)
cd ../../app/client
npm install
cd ..
npm install

Launch in development ▶️

# From repository root (Bash)
./scripts/start.sh

# Or on Windows (PowerShell)
pwsh scripts/start.ps1

The script frees ports 3000/5000 if needed, starts the Flask API, boots the React dev server, and opens the Electron window automatically. React stays inside the Electron shell—no browser tab will appear.

Sample data 📚

If you need fresh demo content, regenerate it:

cd app/backend
python create_sample_data.py

This populates databaseOrigin/ with transcripts and audioOrigin/ with synthesised placeholder audio.

Usage Notes 💡

• Learning view (/): select a lesson on the left, read the large transcript, play audio, record attempts, and review similarity scores on the right panel. Waveforms auto-scale vertically to fit both signals.
• Admin view (/admin): filter materials, record new reference audio, preview recordings, and upload replacements. Transcripts are preserved whenever admin audio is updated.
• Recordings: Uploaded user audio lives in app/backend/audioSelf, and metadata is stored in databaseSelf.

Building for distribution 📦

cd app
npm run build        # Builds the React bundle into client/build

For packaging the Electron app you can integrate electron-packager or a similar tool (not yet scripted in this repo).

Troubleshooting 🧪

• Ports already in use: rerun the start script; it automatically calls npx kill-port 3000 5000.
• Python audio libs failing: ensure the required build tools (e.g., pip install wheel) are available and reinstall librosa dependencies.
• Similarity not appearing: record a new attempt after the reference audio finishes loading; similarity displays when both waveforms are available.

License 📝

Apache License 2.0 – see LICENSE for details.
